Wondering what the EN1822 HEPA filter standard is, and when to use it? This article covers the scope and history of the EN1822 standard, the different EN1822 filter classifications, and the test methods used.

Jump to the relevant section:

• EN1822 Standard Overview & History
• Performance Classifications of the EN1822 Standard.
• Filter Requirements to Meet the EN1822 Standard.
• Applications of EN1822 – when to use it and when not to use it
• Air Filter Testing Procedure Under the EN1822 Standard.

EN1822 HEPA Filter Standard: Overview

EN1822 and its latest version, the EN1822:2019 is the European standard for filters for use in the field of ventilation and air conditioning. It classifies filters into groups based on their filtration efficiency, provides a method to test the performance of air filters, and sets out requirements for the quality and manufacture of air filters.

The standard was first specified in 1998 and has been updated several times to the latest version in use today – the EN1822:2019 standard. The standard is split into 5 parts, with parts 2 to 5 having been replaced by the EN ISO 29463 standard – an international standard for air filters.

1. Part 1: Classification, performance testing, marking (EN1822-1:2019)
2. Part 2: Aerosol production, measuring equipment, and particle-counting statistics (EN ISO 29463-2)
3. Part 3: Testing flat sheet filter material (EN ISO 29463-3)
4. Part 4: Test method for determining the leakage of filter element – Scan method (EN ISO 29463-4)
5. Part 5: Test method for filter elements (EN ISO 29463-5)

EN1822 HEPA Filter Classification

Under the EN1822 standard, filters are split into three groups according to their filtration efficiency:

*Group E: EPA filters (Efficient Particulate Air filter)
*Group H: HEPA filters (High Efficiency Particulate Air filter)
*Group U: ULPA filters (Ultra Low Penetration Air filter)

Below are the 8 different classes defined under EN1822 and their filtration efficiency. Efficiency is defined as the filtration efficiency against the most penetrating particle size (MPPS).

There are other standards around the world that classify HEPA filters differently, such as the MIL-STD-282 and MERV standards in the US.

Requirements of the EN1822 HEPA Standard

In addition to assigning a rating according to a filter’s filtration efficiency, the EN1822 standard has additional requirements for air filters.

These include:

• The filter should have clear markings to prevent incorrect mounting
• The filter should be designed so no leakage occurs along the sealing edge
• The filter should be made of material that can withstand typical usage as well as the environment it is likely to encounter
• Dusts or fibers released from the filter into the air should not be harmful to those exposed

When to Use the EN1822 Standard?

The standard manual defines the scope of the standard to cover “the field of ventilation and air conditioning”, as well as for technical processes such as the pharmaceutical industry. This means the EN1822 standard was not designed to be used for air filters and HEPA filters in standalone air purifiers in homes, schools, and businesses.

While the EN1822 is a good starting point for standardizing HEPA filters inside air purifiers, it may not be entirely relevant. Other standards such as the GB 18801 and AHAM AC-1 standards may be better suited for portable air purifiers.

Read More: Why a Lower Grade Filter is Sometimes BETTER

How are HEPA Filters Tested?

Liquid aerosols are typically used to test the filtration efficiency of a HEPA filter against the most penetrating particle size. There are three steps involved when testing HEPA filters under the EN1822 standard:

• Step 1: Testing sheet filter medium
• Step 2: Leak test of the filter element
• Step 3: Efficiency test of the filter element

The testing procedure is not simple and involves serious equipment. For detailed information on the EN1822 standard test procedures, check out the EN1822 standard manual. The manual was updated in 2009, and then again most recently in 2019.
